Why do I need this machine?

Click on the image to enlarge

Why do I need this machine?

I want to automate the unloading process of parts from the panel saw;
I have frequent damage to parts during handling;
My current process has ergonomic problems due to weight and repetitive strain;
I want to eliminate the risk of accidents caused by handling heavy parts;
I need to reduce workforce costs.

If you have any of these problems, check out this machine!

Automatic Panel Saw Unloader

Prices starting atUSD 23.000,00*

* Check shipping conditions

Automatic Panel Saw Unloader

100% Brazilian manufacturing

Better ergonomics

Quick setup

Touch Screen Panel

Product manufactured in accordance with safety standards

Why choose the automatic panel saw unloader?

Synchronization with the panel saw's rhythm, eliminating unnecessary stops.
Safe, fast, and smooth transfer and stacking of parts.
Increased productivity, eliminating bottlenecks and high workforce costs.
Load capacity up to 2500kg and maximum customizable lift of up to 1950mm from zero point to roller.
Electric stop system composed of linear guides.
High-precision positioning is guaranteed by a servo motor.
100% Automatic system with sensors for precision and real-time control.
Upper table base with driven rollers.
Ball-floating table for better part sliding (air generator not included).
Protection grids, compliant with NR12.

100% Brazilian manufacturing

Better ergonomics

Quick setup

Touch Screen Panel

Product manufactured in accordance with safety standards

The automatic panel saw unloader was developed to eliminate bottlenecks in the panel saw's output process, providing greater efficiency and productivity in production. Its operation is automatic, ensuring safe handling, improved ergonomics, and reduced workforce requirements.

Furniture

Technological highlights

The automatic panel saw unloader consists of a linear motion system with precision guides and a table with driven rollers, allowing smooth and synchronized movement with the panel saw. In addition, the equipment includes a ball-floating table located in front of the lifting platform, making the handling of parts easier.

The system features sensors that ensure precise positioning and real-time adjustment of the table height as new parts are added to the stack. The maximum table height is 1950mm from the zero point to the roller, with a load capacity of up to 2500kg.

Its operation is automatic, controlled by a PLC and operated via HMI, where the operator only enters the dimensions of the part and the equipment receives, adjusts and accommodates each new part received. After reaching the height predetermined by the operator, the stack of parts is automatically transferred to the next conveyor, for continuity of operations.

Control system via HMI and touch screen.

Automatic parts alignment system with servomotor.

Ball-floating table

Equipment dimensions

Dimensions	Measurement unit
Total length (A)	mm	2800
Total width (B)	mm	800
Total height (C)	mm	380-1950
Net weight	kg	500

Dimensions	Measurement unit
Total length (A)	mm	2600
Total width (B)	mm	1346
Total height (C)	mm	1664
Net weight	kg	500

Packaging and delivery

Complete Panel Saw Unloader for export.

Item 1

Item 2

Item 3


Shipping guidance	Packages cannot be toppled over
Packaging specifications	Packages wrapped in stretch film
Total cubic measure	(L) Lenght x (W) Width x (H) Height Package 1: L2600 x W1346 x H1664mm = 5,82m³ = weight 344kg Volume 2: C2800 x L800 x A380mm = 0,851m³ = peso 617kg Package 3: L3000 x W500 x HA900mm = 0,851m³ = weight 176kg
Total net weight	1000kg
Total gross weight	1137kg
Total number of boxes	3 Packages
